Agilent Technologies ENA Series

Appendix D 687
Softkey Functions
Calibration Menu
D. Softkey Functions
(Continued)
Mixer/Converter
Calibration
Scalar Cal (ECal)
Select Ports
3,4 (both)
*2
Select a scalar-mixer calibration for test port 3→4 and 4→3 (both
directions).
None
Cancel Returns to the softkey display in one level higher.
Power Meter Displays the softkey to execute a power calibration.
Use Sensor Selects the channel of the power sensor you want to use for the
measurement of power calibration data.
:SENS{1-16}:CORR:OFFS:COLL:PMET
Port x @
Freq x
Executes a power calibration on test port x by using the frequency
that is set in test port x. The x changes by the selected test port and
calibration method.
:SENS{1-16}:CORR:OFFS:COLL:PMET
Port x @
Freq y
Executes a power calibration on test port x by using the frequency
that is set in test port y. The x and y change by the selected test port
and calibration method.
:SENS{1-16}:CORR:OFFS:COLL:PMET
Port y @
Freq x
Executes a power calibration on test port y by using the frequency
that is set in test port x. The x and y change by the selected test port
and calibration method.
:SENS{1-16}:CORR:OFFS:COLL:PMET
Port y @
Freq y
Executes a power calibration on test port y by using the frequency
that is set in test port y. The y changes by the selected test port and
calibration method.
:SENS{1-16}:CORR:OFFS:COLL:PMET
Return Returns to the softkey display one level higher.
ECal & Done Executes a scalar-mixer calibration and calculates the calibration
coefficient. The GPIB command and parameter change by the
selected test port and calibration method.
:SENS{1-16}:CORR:OFFS:COLL:SMIX2
:SENS{1-16}:CORR:OFFS:COLL:SOLT1
Cancel Displays the softkey to cancel a calibration.
OK Cancels a calibration process and clear the measurement data of
standard.
:SENS{1-16}:CORR:OFFS:COLL:CLE
Cancel Returns to the softkey display one level higher.
Return Returns to the softkey display one level higher.
Clear Displays the softkey that clears the scalar-mixer calibration coefficient.
OK Clears the scalar-mixer calibration coefficient. :SENS{1-16}:CORR:OFFS:CLE
Cancel Returns to the softkey display screen one level higher.
Return Returns to the softkey display screen one level higher.
Cal Trig Source Displays the softkey to set the trigger source for calibration.
Internal Sets the trigger source at calibration to “Internal”.
:SENS{1-16}:CORR:TRIG:SOUR:FREE ON
System Sets the trigger source at calibration to the same trigger source
setting used when measurement is made.
:SENS{1-16}:CORR:TRIG:SOUR:FREE OFF
Return Returns to the “E5070B/E5071B Menu (Top Menu)” on page 646.
*1.Only with Options 313, 314, 413, and 414.
*2.Only with Options 413 and 414.
Key Operation Function SCPI Command
