Agilent Technologies ENA Series

686 Appendix D
Softkey Functions
Calibration Menu
(Continued)
Mixer/Converter
Calibration
Scalar Cal (Manual)
Transmission Displays the softkey to execute THRU standard measurements.
Thru x-y @
Freq x
[Thru]
Executes a THRU calibration on test ports x and y by using the
frequency that is set in test port x. The x and y change by the
selected test port and calibration method.
:SENS{1-16}:CORR:OFFS:COLL:THRU
Thru y-x @
Freq y
[Thru]
Executes a THRU calibration on test ports y and x by using the
frequency that is set in test port y. The x and y change by the
selected test port and calibration method.
:SENS{1-16}:CORR:OFFS:COLL:THRU
Return Returns to the softkey display in one level higher.
Power Meter Displays the softkey to execute a power calibration.
Use Sensor Selects the channel of the power sensor you want to use for the
measurement of power calibration data.
:SENS{1-16}:CORR:OFFS:COLL:PMET
Port x @
Freq x
Executes a power calibration on test port x by using the frequency
that is set in test port x. The x changes by the selected test port and
calibration method.
:SENS{1-16}:CORR:OFFS:COLL:PMET
Port x @
Freq y
Executes a power calibration on test port x by using the frequency
that is set in test port y. The x and y change by the selected test port
and calibration method.
:SENS{1-16}:CORR:OFFS:COLL:PMET
Port y @
Freq x
Executes a power calibration on test port y by using the frequency
that is set in test port x. The x and y change by the selected test port
and calibration method.
:SENS{1-16}:CORR:OFFS:COLL:PMET
Port y @
Freq y
Executes a power calibration on test port y by using the frequency
that is set in test port y. The y changes by the selected test port and
calibration method.
:SENS{1-16}:CORR:OFFS:COLL:PMET
Return Returns to the softkey display in one level higher.
Done Terminates a calibration process and calculates the calibration
coefficients.
:SENS{1-16}:CORR:OFFS:COLL:SAVE
Cancel Displays the softkey to cancel a calibration.
OK Cancels a calibration process and clear the measurement data of
standard.
:SENS{1-16}:CORR:OFFS:COLL:CLE
Cancel Returns to the softkey display in one level higher.
Return Returns to the softkey display in one level higher.
Scalar Cal (ECal) Displays the softkey to execute a scalar-mixer calibration by using the ECal.
Select Ports Displays the softkey to select test ports and calibration methods you want to use for scalar-mixer calibration.
Port 1 Select 1-port calibration for the test port 1. None
: :
:
Port 4
*2
Select 1-port calibration for the test port 4. None
2-1 (fwd) Select a scalar-mixer calibration for test port 1→2 (forward). None
1-2 (rev) Select a scalar-mixer calibration for test port 2→1 (reverse). None
2,1 (both) Select a scalar-mixer calibration for test port 1→2 and 2→1 (both
directions).
None
: :
:
4-3 (fwd)
*2
Select a scalar-mixer calibration for test port 3→4 (forward). None
3-4 (rev)
*2
Select a scalar-mixer calibration for test port 4→3 (reverse). None
Key Operation Function SCPI Command
