710 Appendix D
Softkey Functions
Save/Recall Menu
(Continued)
Recall by File Name Displays softkeys that show the state file names for recalling settings.
aaa Recalls from the internal hard disk drive (D:\State) the settings saved as the
filename used in the softkey label.
:MMEM:LOAD
bbb Recalls from the internal hard disk drive (D:\State) the settings saved as the
filename used in the softkey label.
:MMEM:LOAD
:
xxx yyy zzz Recalls from the internal hard disk drive (D:\State) the settings saved as the
filename used in the softkey label.
:MMEM:LOAD
Return Returns to the softkey display screen one level higher.
Save Channel Displays softkeys for saving settings for each channel into registers A to D (volatile memory).
State A Saves the current settings for each channel into registers A.
:MMEM:STOR:CHAN A
State B Saves the current settings for each channel into registers B.
:MMEM:STOR:CHAN B
State C Saves the current settings for each channel into registers C.
:MMEM:STOR:CHAN C
State D Saves the current settings for each channel into registers D.
:MMEM:STOR:CHAN D
Clear States Displays softkeys for clearing registers.
OK Clears all registers (A - D).
:MMEM:STOR:CHAN:CLE
Cancel Returns to the softkey display screen one level higher.
Return Returns to the softkey display screen one level higher.
Recall Channel Displays softkeys for recalling settings for each channel from registers A to D (volatile memory).
State A Recalls the current settings for each channel from registers A.
:MMEM:LOAD:CHAN A
State B Recalls the current settings for each channel from registers B.
:MMEM:LOAD:CHAN B
State C Recalls the current settings for each channel from registers C.
:MMEM:LOAD:CHAN C
State D Recalls the current settings for each channel from registers D.
:MMEM:LOAD:CHAN D
Return Returns to the softkey display screen one level higher.
Save Type Displays softkeys for selecting the types of data to be saved.
State Only Saves settings only.
:MMEM:STOR:STYP STAT
State & Cal Saves settings and calibration data.
:MMEM:STOR:STYP CST
State & Trace Saves settings and trace data.
:MMEM:STOR:STYP DST
All Saves settings, calibration data, and trace data.
:MMEM:STOR:STYP CDST
Cancel Returns to the softkey display screen one level higher.
Channel/Trace Selects the save target for saving settings from all channels/traces (All) or
displayed channel/traces only (
Disp Only).
:MMEM:STOR:STYP SALL
Save Trace Data Opens a dialog box for saving trace data as a CSV (comma-separated value) file.
A CSV file can be opened in spreadsheet software such as Microsoft
“ Excel“.
:MMEM:STOR:FDAT
Explorer... Opens Windows Explorer for organizing (cut, copy, paste, delete, rename, format)
files and folders. The operation is same as Windows 98 computers. Users can
modify files and folders in drive A: (floppy disk drive) and drive D: (user
directory). Be sure not to modify any files and folders in drives other than drive A:
and drive D:. Doing so will cause malfunctions.
:MMEM:MDIR
:MMEM:COPY
:MMEM:DEL
Key Operation Function SCPI Command
