Agilent Technologies ENA Series

722 Appendix D
Softkey Functions
System Menu
(Continued)
Misc Setup
Color Setup
Normal
Mem Trace 1 Displays softkeys for setting up the color of the memory trace of Trace
1. The lower-level softkeys are the same as those for
Data Trace 1.
:DISP:COL{1-2}:TRAC1:MEM
: :
:
Mem Trace 9 Displays softkeys for setting up the color of the memory trace of Trace
9. The lower-level softkeys are the same as those for
Data Trace 1.
:DISP:COL{1-2}:TRAC9:MEM
Graticule
Main
Displays softkeys for setting up the color of the graticule labels and the
outer frame of graphs. The lower-level softkeys are the same as those
for
Data Trace 1.
:DISP:COL{1-2}:GRAT1
Graticule Sub Displays softkeys for setting up the color of the graticule lines in
graphs. The lower-level softkeys are the same as those for
Data Trace 1.
:DISP:COL{1-2}:GRAT2
Limit Fail Displays softkeys for setting up the color of the fail label of the limit
test. The lower-level softkeys are the same as those for
Data Trace 1.
:DISP:COL{1-2}:LIM1
Limit Line Displays softkeys for setting up the color of the limit line of the limit
test. The lower-level softkeys are the same as those for
Data Trace 1.
:DISP:COL{1-2}:LIM2
Background Displays softkeys for setting up the color of the background. The
lower-level softkeys are the same as those for
Data Trace 1.
:DISP:COL{1-2}:BACK
Reset Color Resets the color to the factory seting state.
:DISP:COL{1-2}:RES
Return Returns to the softkey display screen one level higher.
Invert Displays softkeys for setting up the color of the inverted display. The lower-level softkeys are the same as those for
Nomal.
Return Returns to the softkey display screen one level higher.
Channel/Trace
Setup
Displays softkeys for setting up the maximum numbers of the channels and traces.
1 Channels
4
Traces
Sets the maximum number of channels to 1 and the maximum number
of traces to 4.
None
2 Channels
4
Traces
Sets the maximum number of channels to 2 and the maximum number
of traces to 4.
None
4 Channels
16
Traces
Sets the maximum number of channels to 4 and the maximum number
of traces to 16.
None
9 Channels
9
Traces
Sets the maximum number of channels to 9 and the maximum number
of traces to 9.
None
12 Channels
6
Traces
Sets the maximum number of channels to 12 and the maximum
number of traces to 6.
None
16 Channels
4
Traces
Sets the maximum number of channels to 16 and the maximum
number of traces to 4.
None
1 Ch / 4 Tr
200001 Points
Sets the maximum number of channels to 1, the maximum number of
traces to 4, and the upper limit of the measurement point to 20001.
None
Return Returns to the softkey display screen one level higher.
Preset Setup Displays softkeys to executes the preset function.
State Displays the softkeys to set the type of preset to be executed.
Factory Executes the preset function to recall the factory state. None
User Executes the preset function to recall a user-specified state. None
Confirm Toggles on/off whether to display the softkeys for confirmation at the
execution of the preset function.
None
Key Operation Function SCPI Command
