Chapter 3 71
Setting Measurement Conditions
Setting Stimulus Conditions
3. Setting Measurement
Conditions
Setting the Sweep Range with the Lowest and Highest Values
Step 1. Press or to select the channel whose sweep range will be set.
Step 2. Press .
Step 3. Using the ENTRY block keys on the front panel, input the lowest value.
Step 4. Press .
Step 5. Using the ENTRY block keys on the front panel, input the highest value.
Setting the Sweep Range with the Center Value and a Span
Step 1. Press or to select the channel whose sweep range will be set.
Step 2. Press .
Step 3. Using the ENTRY block keys on the front panel, input the center value.
Step 4. Press .
Step 5. Using the ENTRY block keys on the front panel, input a span value.
Setting the Sweep Range Using the Marker
Step 1. In the channel window whose range must be set, place the active marker on the active trace
to a position that corresponds to the new range (to the lowest, highest, or center value).
Step 2. Press .
Step 3. Press the softkey that corresponds to each value.
Softkey Function
Marker → Start Sets the lowest value to the stimulus value of the active marker on the
currently active trace.
Marker → Stop Sets the highest value to the stimulus value of the active marker on the
currently active trace.
Marker → Center Sets the center value to the stimulus value of the active marker on the
currently active trace.
NOTE If the reference marker is on and the stimulus value of the active marker is expressed by a
value relative to the reference marker, the absolute stimulus value will be used to set the
new sweep range.
