Ashida ADR233B - Page 191

Doc ID : ADR233B/IM/01
Ref ID : ADR233B/IM/CS
Rev No. : 05
Page No. : 191 of 479
ADR233B
Model 10
20-Bytes
ASCII
R 40021 – 40030
Version
10
20-Bytes
ASCII
R 40031 – 40040
Sr.
No.
Function
Code
Register No. of
Regs
Format Reg.
Type
Address
Map
3 Time
Synchronization
(Unicast /
Broadcast)
03/16
Year 1 16 bit R/W 42049
Month- Day 1 16 bit R/W 42050
Hour, Min 1 16 bit R/W 42051
Milliseconds 1 16 bit R/W 42052
Sr. No. Function
Code
Register No. of
Regs
Format Reg.
Type
Address Map
4 Status and
Logical Status
02
PROT Ready 1 1 bit R 12772
W1_CBOpr Alm 1 1 bit R 12777
W1_CBOpn Sup 1 1 bit R 12778
W1_ CB Trip /
CB Close
1 1 bit R 12780
W1ClsFail 1 1 bit R 12781
W1OpnFail 1 1 bit R 12782
W1_TCS Alarm 1 1 bit R 12783
W2_CBOpr Alm 1 1 bit R 12786
W2_CBOpn Sup 1 1 bit R 12787
W2_ CB Trip /
CB Close
1 1 bit R 12789
W2ClsFail 1 1 bit R 12790
W2OpnFail 1 1 bit R 12791
W2_TCS Alarm 1 1 bit R 12792
General P 1 1 bit R 15001
General T 1 1 bit R 15002
W1_IP>1 P 1 1 bit R 15009
W1_IP>1 T 1 1 bit R 15010
W1_IP>2 P 1 1 bit R 15011
W1_IP>2 T 1 1 bit R 15012
W1_IP>3 P 1 1 bit R 15013
W1_IP>3 T 1 1 bit R 15014
