ADR233B
RLGGIO2$CO$SPCSO2$Oper$ctlVal
RLGGIO2$ST$SPCSO2$stVal dchg
RLGGIO2$CO$SPCSO3$Oper$ctlVal
RLGGIO2$ST$SPCSO3$stVal dchg
RLGGIO2$CO$SPCSO4$Oper$ctlVal
RLGGIO2$ST$SPCSO4$stVal dchg
RLGGIO2$CO$SPCSO5$Oper$ctlVal
RLGGIO2$ST$SPCSO5$stVal dchg
RLGGIO2$CO$SPCSO6$Oper$ctlVal
RLGGIO2$ST$SPCSO6$stVal dchg
RLGGIO2$CO$SPCSO7$Oper$ctlVal
RLGGIO2$ST$SPCSO7$stVal dchg
RLGGIO2$CO$SPCSO8$Oper$ctlVal
RLGGIO2$ST$SPCSO8$stVal dchg
RL9-16 Binary Control Output 9-16
Data Attribute Dataset
RLGGIO7$CO$SPCSO1$Oper$ctlVal
RLGGIO7$ST$SPCSO1$stVal dchg
RLGGIO7$CO$SPCSO2$Oper$ctlVal
RLGGIO7$ST$SPCSO2$stVal dchg
RLGGIO7$CO$SPCSO3$Oper$ctlVal
RLGGIO7$ST$SPCSO3$stVal dchg
RLGGIO7$CO$SPCSO4$Oper$ctlVal
RLGGIO7$ST$SPCSO4$stVal dchg
RLGGIO7$CO$SPCSO5$Oper$ctlVal
RLGGIO7$ST$SPCSO5$stVal dchg
RLGGIO7$CO$SPCSO6$Oper$ctlVal
RLGGIO7$ST$SPCSO6$stVal dchg
RLGGIO7$CO$SPCSO7$Oper$ctlVal
RLGGIO7$ST$SPCSO7$stVal dchg
RLGGIO7$CO$SPCSO8$Oper$ctlVal
RLGGIO7$ST$SPCSO8$stVal dchg
RL17-24 Binary Control Output 17-24 (Available only in M19” model)
Data Attribute Dataset
RLGGIO32$CO$SPCSO1$Oper$ctlVal
RLGGIO32$ST$SPCSO1$stVal dchg
RLGGIO32$CO$SPCSO2$Oper$ctlVal
RLGGIO32$ST$SPCSO2$stVal dchg
RLGGIO32$CO$SPCSO3$Oper$ctlVal
RLGGIO32$ST$SPCSO3$stVal dchg
