Ashida ADR233B - Page 226

Doc ID : ADR233B/IM/01
Ref ID : ADR233B/IM/CS
Rev No. : 05
Page No. : 226 of 479
ADR233B
RLGGIO32$CO$SPCSO4$Oper$ctlVal
RLGGIO32$ST$SPCSO4$stVal dchg
RLGGIO32$CO$SPCSO5$Oper$ctlVal
RLGGIO32$ST$SPCSO5$stVal dchg
RLGGIO32$CO$SPCSO6$Oper$ctlVal
RLGGIO32$ST$SPCSO6$stVal dchg
RLGGIO32$CO$SPCSO7$Oper$ctlVal
RLGGIO32$ST$SPCSO7$stVal dchg
RLGGIO32$CO$SPCSO8$Oper$ctlVal
RLGGIO32$ST$SPCSO8$stVal dchg
RL25-32 Binary Control Output 25-32 (Available only in M19” model)
Data Attribute Dataset
RLGGIO33$CO$SPCSO1$Oper$ctlVal
RLGGIO33$ST$SPCSO1$stVal dchg
RLGGIO3$CO$SPCSO2$Oper$ctlVal
RLGGIO33$ST$SPCSO2$stVal dchg
RLGGIO33$CO$SPCSO3$Oper$ctlVal
RLGGIO33$ST$SPCSO3$stVal dchg
RLGGIO33$CO$SPCSO4$Oper$ctlVal
RLGGIO33$ST$SPCSO4$stVal dchg
RLGGIO33$CO$SPCSO5$Oper$ctlVal
RLGGIO33$ST$SPCSO5$stVal dchg
RLGGIO33$CO$SPCSO6$Oper$ctlVal
RLGGIO33$ST$SPCSO6$stVal dchg
RLGGIO33$CO$SPCSO7$Oper$ctlVal
RLGGIO33$ST$SPCSO7$stVal dchg
RLGGIO33$CO$SPCSO8$Oper$ctlVal
RLGGIO33$ST$SPCSO8$stVal dchg
Green LED 1-16 Green LEDs 1-16
Data Attribute Dataset
GLEDGGIO8$ST$Ind1$stval dchg
GLEDGGIO8$ST$Ind2$stVal dchg
GLEDGGIO8$ST$Ind3$stVal dchg
GLEDGGIO8$ST$Ind4$stVal dchg
GLEDGGIO8$ST$Ind5$stVal dchg
GLEDGGIO8$ST$Ind6$stVal dchg
GLEDGGIO8$ST$Ind7$stVal dchg
GLEDGGIO8$ST$Ind8$stVal dchg
GLEDGGIO8$ST$Ind9$stval dchg
GLEDGGIO8$ST$Ind10$stVal dchg
