Ashida ADR233B - Page 263

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 263 of 479
ADR233B
Setting Group
Factory Defaults
No Operation
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Factory Defaults can be set i.e. All
Settings, No Operation, Setting Group 1, Setting Group 2,
Setting Group 3 and Setting Group 4.
Press the Minus / Down arrow key (- /) to move to the next
option.
Setting Group
Active Group
G1
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Active Group can be set i.e. G1 / G2 /
G3 / G4.
Press the Minus / Down arrow key (- /) to move to the next
option.
Setting Group
Copy from
G1
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Copy from can be set i.e. G1 / G2 / G3 /
G4.
Press the Minus / Down arrow key (- /) to move to the next
option.
Setting Group
Copy to
No Operation
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Copy to can be set i.e. No Operation /
G1 / G2 / G3 / G4.
Press the Minus / Down arrow key (- /) to move to the next
option.
Setting Group
G1
Enabled
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the G1 can be set i.e. Disabled / Enabled /
TimeEnabled.
Note: When set as Enabled
Press the Minus / Down arrow key (- /) to move to the next
option.
