PROTECTIONS
W1 50BF
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W1 50BF can be set i.e. Disabled /
Enabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
PROTECTIONS
W2 50BF
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the W2 50BF can be set i.e. Disabled /
Enabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
PROTECTIONS
Thermal Overload
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Thermal Overload can be set i.e.
Disabled / Enabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
PROTECTIONS
Through Fault
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Through Fault can be set i.e. Disabled /
Enabled.
Press the Right arrow key () to move to the Main Menu.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
SAVE SETTINGS
This window will flash for a moment and it will move to the
Main Menu.
