ADR233B
Hrm BLK Criteria
t Cross Blocking
5.00 s
Range 0 – 10 s
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the t Cross Blocking can be set.
The setting range is from 0 to 10s in step of 0.01s
Press the Left arrow key () to move to the next option.
Ph Differential
Hrm BLK Criteria
Blocked
Editable Setting
Password protected window for “Hrm BLK Criteria ” setting
i.e. Disabled / Blocked / Restrain
Press the Minus / Down arrow key (- /) to move to the next
option.
Ph Differential
5th Hrm Diff BLK
Enabled
Editable Setting
Password protected window for “5th Hrm Diff BLK” setting
i.e. Disabled / Enabled.
Press the Right arrow key () to move to the next option.
5th Hrm Diff BLK
5H Diff Threshold
30 %
Range 5 – 70 %
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 5H Diff Threshold can be set.
The setting range is from 5 to 70% in step of 1%.
Press the Minus / Down arrow key (- /) to move to the next
option.
5th Hrm Diff BLK
t 5th Hrm
0.00 s
Range 0 – 10 s
Read Only Setting
This window shows the t 5th Hrm.
Press the Right arrow key () to move to the next option.
Press

Key
For SAVE
Press Target Reset
Key For Cancel
Press the Left arrow key () to SAVE the changes.
