Ashida ADR233B - Page 317

Doc ID :ADR233B/IM/01
Ref ID : ADR233B/IM/UG
Rev No. : 05
Page No. : 317 of 479
ADR233B
Ph Differential
Hrm BLK Criteria
Blocked
Editable Setting
Password protected window for “Hrm BLK Criteria” setting
i.e. Disabled / Blocked / Restrain
Press the Right arrow key () to move to the next option.
Hrm BLK Criteria
Hrm BLK Mode
2nd Hrm & 4th Hrm
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Hrm BLK Mode can be set i.e. Disabled
/ 2nd Hrm / 2nd Hrm & 4th Hrm.
Note: when set as 2nd Hrm & 4th Hrm
Press the Minus / Down arrow key (- /) to move to the next
option.
Hrm BLK Criteria
2nd Hrm Threshold
20 %
Range 5 – 70 %
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 2nd Hrm Threshold can be set.
The setting range is from 5 to 70% in step of 1%.
Press the Minus / Down arrow key (- /) to move to the next
option.
Hrm BLK Criteria
4th Hrm Threshold
20 %
Range 5 – 70 %
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the 4th Hrm Threshold can be set.
The setting range is from 5 to 70% in step of 1%.
Press the Minus / Down arrow key (- /) to move to the next
option.
Hrm BLK Criteria
Cross Blocking
Time Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the Cross Blocking can be set. i.e. Disabled
/ Enabled / TimeEnabled
Note: When set as TimeEnabled.
Press the Minus / Down arrow key (- /) to move to the next
option.
