ADR233B
Ground OC
IE>1 D/O Char
DT
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IE>1 D/O Char can be set i.e. Disabled /
DT / IDMT.
Note: If Disabled the D/O Characteristics function is blocked.
Press the Minus / Down arrow key (- /) to move to the next
option.
IF DT
Ground OC
t IE>1 D/O Delay
0.01 S
Range 0 – 100s
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the tIE>1 D/O Delay can be set.
The setting range is from 0s to 100s in step of 0.01s
Press the Minus / Down arrow key (- /) to move to the next
option.
IF IDMT
Ground OC
IE>1 D/O TMS
1.000
Range 0.025 – 1.2
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IE>1 D/O TMS can be set.
The setting range is from 0.025 to 1.2 in step of 0.001.
Press the Minus / Down arrow key (- /) to move to the next
option.
Ground OC
IE>1 2H BLK
Enabled
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IE>1 2H BLK can be set i.e. Disabled /
Enabled.
Note: If Disabled the IE>1 2H BLK function is blocked.
Press the Minus / Down arrow key (- /) to move to the next
option.
IF Enabled
Ground OC
IE>1 2H Thresh
10 %
Range 5 – 70 %
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IE>1 2H Thresh can be set.
The setting range is from 5 to 70% in step of 1%
Press the Minus / Down arrow key (- /) to move to the next
option.
