ADR233B
Ground OC
Ground OC

Editable Setting
Password protected window for “REF Ground OC” setting
i.e. IE>1 Enable, IE>2 Enable and IE>3 Enable can be set as
Disabled / Enabled.
Press the Right arrow key () to move to the next option.
Ground OC
IE>1 Enable
Enabled
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IE>1 Enable can be set i.e. Disabled /
Enabled.
Note: When set as Enabled
Press the Right arrow key () to move to the next option.
Ground OC
IE>1 Curve
Definite Time
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IE>1 Curve can be set i.e. Definite Time
/ IEC S Inverse / ST Inverse 1.3S / IEC V Inverse / IEC E
Inverse / UK LT Inverse / IEEE M Inverse / IEEE V Inverse /
IEEE E Inverse / US Inverse / US ST Inverse.
Note: When set as Definite Time Curve.
Press the Minus / Down arrow key (- /) to move to the next
option.
Ground OC
IE>1
1.00 A
0.05 – 35.00 xIn
Editable Setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IE>1 can be set.
The setting range is from 0.05 to 35.00 xIn in step of 0.01 xIn.
Press the Minus / Down arrow key (- /) to move to the next
option.
Ground OC
t IE>1 DT Delay
1.00 s
Range 0 – 1899.9s
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the tIE>1 DT Delay can be set.
The setting range is from 0 (Inst) to 1899.9sec in step of
0.01sec.
Press the Minus / Down arrow key (- /) to move to the next
option.
