ADR233B
Ground OC
IE>1 D/O Char
DT
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IE>1 D/O Char can be set i.e. Disabled /
DT / IDMT.
Note: If Disabled the D/O Characteristics function is blocked.
Press the Minus / Down arrow key (- /) to move to the next
option.
IF DT
Ground OC
t IE>1 D/O Delay
0.01 S
Range 0 – 100s
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the tIE>1 D/O Delay can be set.
The setting range is from 0s to 100s in step of 0.01s
Press the Minus / Down arrow key (- /) to move to the next
option.
Ground OC
IE>1 2H BLK
Enabled
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IE>1 2H BLK can be set i.e. Disabled /
Enabled.
Note: If Disabled the IE>1 2H BLK function is blocked.
Press the Minus / Down arrow key (- /) to move to the next
option.
IF Enabled
Ground OC
IE>1 2H Thresh
5 %
Range 5 – 70%
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IE>1 2H Thresh can be set.
The setting range is from 5 to 70% in step of 1%.
Press the Minus / Down arrow key (- /) to move to the next
option.
Ground OC
IE>1 UB2H
4.0 A
4.0 – 32.0 xIn
Editable setting
By using the Plus / Up arrow key (+ /) or the Minus / Down
arrow key (- /) the IE>1 UB2H can be set.
The setting range is from 4.0 to 32.0 xIn in step 0.1 xIn.
Press the Right arrow key () to move to the next option.
