9.5.2 CB Control (If Enabled)
W1 CB CONTROL
TCS Enable
Logic Low
W1 CB CONTROL
TCS Delay
5.0 S
Range 0.1 – 10s
3 4
W1 CB CONTROL
CB Open S’vision
Enabled
3 4
W1 CB CONTROL
CB Open Time
300 ms
Range 50 – 1000ms
3 4
W1 CB CONTROL
CB Open Alarm
Enabled
3 4
W1 CB CONTROL
CB Oper. Counter
20000
Range 10 – 50000
W1 CB CONTROL
CB Control by
Local
3 4
3 4
W1 CB CONTROL
t CB Open Pulse
0.50 s
Range 0.1 – 50s
W1 CB CONTROL
t CB Close Pulse
0.50 s
Range 0.1 – 50s
3 4
3 4
SAVE Settings
DISCARD Settings
4
Press 3 Key
For Save
Press Target Reset
Key For Cancel
Target Reset
3
MEASUREMENT
GLOBAL
CB CONTROL
4
REOPRTING
6 5
W1 CB CONTROL 4
W2 CB CONTROL
6 5
W1 CB CONTROL
CB Rated I
100 A
3 4
W1 CB CONTROL
m constant
1
3 4
Note: The CB Control setting of W2 CB Control is similar to W1 CB Control.
