Ashida ADR233B - Page 434

ADR233B
Doc ID : ADR233B_IM_01
Ref ID : ADR233B/IM/FC
Rev No. : 05
Page No. : 434 of 479
9.11.5.4 Ground OC ( Definite Time Curve )
Ground OC
IE>1 Curve
Definite Time
Ground OC
IE>1
1.00 A
0.05 – 35.00 xIn
3 4
Ground OC
t IE>1 DT Delay
0.00 s
Range 0 – 1899.9s
3 4
3 4
Ground OC
t IE>1 D/O Delay
0.01 S
Range 0 – 100s
3 4
3 4
3 4
Ground OC
IE>1 D/O Char
DT
6 5
Ground OC
IE>1 2H BLK
Enabled
Ground OC
IE>1 UB2H
4.0 A
4.0 – 32.0 xIn
Ground OC
IE>1 2H Thresh
5 %
Range 5 – 70%
3 4
SAVE Settings
DISCARD Settings
4
Press 3 Key
For Save
Press Target Reset
Key For Cancel
Target Reset
3
6 5
REF
Phase OC
Ground OC
4
Residual OC
6
PROTECTION
CLEAR RECORDS
OUTPUT & LED TEST
GROUP 1
4
Ground OC
Ground OC
4
6 5
Ground OC
IE>1 Enable
Enabled
Note : The Ground OC settings of IE>2 Enable and IE>3 Enable for Definite Time Curve is similar to
Ground OC setting of IE>1 Enable.
