ADR233B
B3 – B4 A19 – A20 A1 – A3 Current IA-W1_5A
Current IB- W1
B5 - B6 A21 – A22 A4 – A5 Current IB-W1_1A
B7 – B8 A23 – A24 A4 – A6 Current IB-W1_5A
Current IC- W1
B9 – B10 A25 – A26 A7 – A8 Current IC-W1_1A
B11 – B12 A27 – A28 A7 – A9 Current IC-W1_5A
Voltage V B17 – B18 A29 – A30 B11 – B12 PT input.
Power Supply E1, E3 C1 – C2 C1 – C2 Power Supply P(+) / P(-)
IRIG B Port F1, F2 B1, B2 - IRIG B Port (+ / -)
RS485 Port F3, F4, F5 B3, B5,B7 D3 – D4 – D5 RS485 (D- / D+ / GND)
LAN-1 Ethernet Ethernet Ethernet Ethernet
LAN-2 Ethernet Ethernet Ethernet Ethernet
Input1 H1 – H2 C7 – C8 C3 – C7 H IN1 (+ / -)
Input2 H3 – H4 C7 – C9 C3 – C8 H IN2 (+ / -)
Input3 H5 – H6 C7 – C10 C3 – C9 H IN3 (+ / -)
Input4 H7 – H8 C7 – C11 C3 – C10 H IN4 (+ / -)
Input5 H9 – H10 C7 – C12 C3 – C11 H IN5 (+ / -)
Input6 H11 – H12 C7 – C13 C3 – C12 H IN6 (+ / -)
Input7 H13 – H14 C7 – C14 C3 – C13 H IN7 (+ / -)
Input8 H15 – H16 C7 – C15 C3 – C14 H IN8 (+ / -)
Input1 I1 – I2 C1 – C2 (TC1) C3 – C15 I IN1 (+ / -)
Input2 I3 – I4 C3 – C4 (TC2) C3 – C16 I IN2 (+ / -)
Input3 I5 – I6 - C4 – C5 I IN3 (+ / -)
Input4 I7 – I8 - C4 – C6 I IN4 (+ / -)
Input5 I9 – I10 - - I IN5 (+ / -)
Input6 I11 – I12 - - I IN6 (+ / -)
Input7 I13 – I14 - - I IN7 (+ / -)
Input8 I15 – I16 - - I IN8 (+ / -)
Input1 N1 – N2 * - - N IN1 (+ / -)
Input2 N3 – N4 * - - N IN2 (+ / -)
Input3 N5 – N6 * - - N IN3 (+ / -)
Input4 N7 – N8 * - - N IN4 (+ / -)
Input5 N9 – N10 * - - N IN5 (+ / -)
Input6 N11 – N12 * - - N IN6 (+ / -)
Input7 N13 – N14 * - - N IN7 (+ / -)
Input8 N15 – N16 * - - N IN8 (+ / -)
Input1 O1 – O2 * - - O IN1 (+ / -)
Input2 O3 – O4 * - - O IN2 (+ / -)
Input3 O5 – O6 * - - O IN3 (+ / -)
