Ref ID : ADR233B/IM/TC
Rev No. : 05
Page No. : 470 of 479
ADR233B
Input4 O7 – O8 * - - O IN4 (+ / -)
Input5 O9 – O10 * - - O IN5 (+ / -)
Input6 O11 – O12 * - - O IN6 (+ / -)
Input7 O13 – O14 * - - O IN7 (+ / -)
Input8 O15 – O16 * - - O IN8 (+ / -)
Output1 J1 – J2 C16 – C18 C17 – C18 J OUT 1 (C–NO)
Output2 J3 – J4 C17 – C19 C19 – C20 J OUT 2 (C–NO)
Output3 J5 – J6 C20 – C22 – C24 C21 – C22 J OUT 3 (C–NO)
Output4 J7 – J8 C21 – C23 – C25 C23 – C24 J OUT 4 (C–NO)
Output5 J9 – J10 C26 – C28 C26 – C27 – C28 J OUT 5 (C–NO–NC)
Output6 J11 – J12 C27 – C29 C29 – C30 J OUT 6 (C–NO)
Output7 J13 – J14 C30 – C40 C31 – C32 J OUT 7 (C–NO)
Output8 J15 – J16 – J17 C31 – C40 C33 – C34 J OUT 8 (C–NO)
Output1 K1 – K2 C32 – C40 C35 – C36 K OUT 1 (C–NO)
Output2 K3 – K4 C33 – C40 C37 – C38 K OUT 2 (C–NO)
Output3 K5 – K6 C34 – C40 C39 – C40 K OUT 3 (C–NO)
Output4 K7 – K8 C35 – C40 - K OUT 4 (C–NO)
Output5 K9 – K10 C36 – C40 - K OUT 5 (C–NO)
Output6 K11 – K12 C37 – C40 - K OUT 6 (C–NO)
Output7 K13 – K14 C38 – C40 - K OUT 7 (C–NO)
Output8 K15 – K16 – K17 C39 – C40 - K OUT 8 (C–NO–NC)
Output1 L1 – L2 * - - L OUT 1 (C–NO)
Output2 L3 – L4 * - - L OUT 2 (C–NO)
Output3 L5 – L6 * - - L OUT 3 (C–NO)
Output4 L7 – L8 * - - L OUT 4 (C–NO)
Output5 L9 – L10 * - - L OUT 5 (C–NO)
Output6 L11 – L12 * - - L OUT 6 (C–NO)
Output7 L13 – L14 * - - L OUT 7 (C–NO)
Output8 L15 – L16 – L17 * - - L OUT 8 (C–NO–NC)
Output1 M1 – M2 * - - M OUT 1 (C–NO)
Output2 M3 – M4 * - - M OUT 2 (C–NO)
Output3 M5 – M6 * - - M OUT 3 (C–NO)
Output4 M7 – M8 * - - M OUT 4 (C–NO)
Output5 M9 – M10 * - - M OUT 5 (C–NO)
Output6 M11 – M12 * - - M OUT 6 (C–NO)
Output7 M13 – M14 * - - M OUT 7 (C–NO)
Output8 M15 – M16 – M17 * - - M OUT 8 (C–NO–NC)
