Configuration
Parameter manual b maXX BM3000
Document no.: 5.12001.07 Baumüller Nürnberg GmbH
234
of 820
4.4
125.17 Test signal amplitude
This parameter is used to set the amplitude of the test signal, Parameter Z125.22–, in
volts or to disable its generation.
The frequency of the sine wave oscillation is dependent on Parameter Z125.7–.
*) see also parameter Z125.7–
125.18 Correction gain Channel 1
Additional standardization on Channel 1
125.19 Correction gain Channel 2
Additional standardization on Channel 2
Parameter which are using the same standardization factor, but generally have different
dimensions can be rescaled channel-dependent with both correction gains.
Example: Z18.58– Position set value angle on channel 1
Z18.60– Position error rev+angle on channel 2
both use Z125.12– Position scaling
Parameter 125.17 Signal
0 V No signal generated.
If Parameter 125.22 is selected in Parameter 125.1/2, the
(constant) value of Parameter 125.22 will be written to the
analog output.
>0 V…10 V Generation of a sine wave signal of amplitude >0 V…10 V
and frequency (see below) with output in Parameter 125.22.
If Parameter 125.22 is selected in Parameter 125.1/2, the
value of Parameter 125.22 will be written to the analog out
-
put.
Value in Z125.7–
Visu Task No
Output cycle time
[µs]
Oscillation fre-
quency [Hz]
1 62,5 16
2 250 * 4
3 1000 1
