Commissioning
Parameter
Display
ENT
Please note: If you changed the configuration, the device resets.
Please execute the before mentioned steps anew.
− BCR-motor series of Bonfiglioli Vectron

oder
− BTD- motor series of Bonfiglioli Vectron

oder
− Other synchronous servo motor

ENT
Enter motor data according to the name plate:
Standstill Torque M0 in Nm
 .
ENT
Set the value using the arrow keys.
Note
Press the arrow keys for 1 s to set each figure individually.
P371
Rated current in A

ENT
If a BCR or BTD motor of Bonfiglioli Vectron was selected, the follow-
ing data are preselected based on the standstill torque and the rated
current. If a BONFIGLIOLI motor is connected check and confirm the
values. If a motor of another manufacturer was connected, please
enter the values manually.
P370
Rated voltage in V
The real AC rated voltage of the motor has to be set up (marked bold
in the following). This results in entering:
AC 330 V Motor = DC 560 V Motor = AC 400 V FI System voltage
AC 200 V Motor = DC 320 V Motor = AC 230 V FI System voltage
 
ENT
P376
Rated mechanical power in kW.
For the BCR and BTD motors, the rated mechanical power is listed in
the motor catalogue.
ENT
P372
Rated speed in rpm.
  
ENT
P373
No. of pole pairs
 .
ENT
P375
Rated frequency in Hz
 
ENT
If “STO” is displayed, enable must be switched on via STOA (X11.3)
and STOB (X13.3).
 
Auto-tuning (auto set-up). Confirm to start the measurement of fur-
ther motor parameters. Consider the following note for another set-
1
Control of a synchronous motor, for higher demands on speed or torque accuracy. In the case of control via
operator panel: Select “Synch”. PMSM: Permanently magnetized synchronous motor.
1 s
 

66
Operating Instructions
Agile 06/2013 First commissioning
