100-412-234 REV. 06 95

5.11 Still Need Help?

Branson is pleased that you chose our product and we are here for you! If you need parts

or technical assistance with your 2000Xc Power Supply system, call your local Branson

representative or contact Branson customer service by calling the appropriate department

as indicated in 1.3 Warranty Statement, Disclaimer.
