58 100-412-234 REV. 06

5.1 About Installation

This chapter is intended to help the installer with the basic installation and setup of your

new 2000Xc welding system.

International safety labels are found on the power supply and actuator. Those that are of

importance during installation of the system are identified in the figures in this and other

chapters of this manual.

CAUTION

The actuator and related components are heavy. Handling,

unpacking, and installation can require help or the use of lifting

platforms or hoists.
