Branson 2000Xc - Table 8.9 Removing the Power Supply Module

214 100-412-234 REV. 06
8.8.5 Power Supply Module
The ultrasonic power supply module is affixed to the bottom of the power supply box with
four screws through the bottom board. To remove the power supply module, perform the
following steps listed in Table 8.9.
To remove the power supply module, take the following steps:
To reinstall the power supply module, reverse the removal procedure.
CAUTION
Transfer the DIP switch settings from the original module to the new
module.
If installing a 1.1kw or 800w power supply module into a 117 VAC
power supply, move the 115/230 jumper to the 115 position.
Table 8.9 Removing the Power Supply Module
Step Action
1 Turn off the power supply.
2 Unplug the main power.
3 Allow at least two minutes for capacitor discharge.
4
Using a #2 Phillips screwdriver, remove 7 screws from the 2000Xc cover (3
on each side, 1 on the rear). Remove the cover.
5 Disconnect P13, P51, and P60 from controller board.
6 Disconnect P21 and P24 from the lower board.
7 Use a Phillips screwdriver to remove retaining screws.
8 Slide the module out of the power supply
