Branson 2000Xc - Table B.3 no Cycle Alarms and Messages, with Probable Cause and Corrective Action

100-412-234 REV. 06 235
B.1.4 No Cycle Alarms
Table B.3 No Cycle Alarms and Messages, with Probable Cause and Corrective Action
Alarm
ID
Display Message Alarm Condition/Cause Corrective Action
702 Trigger Timeout
Trigger force was not
achieved within the 10
second allowed time.
Verify that the part is in
the fixture; verify that
there is adequate
pressure from your
pneumatic supply. Verify
stroke length <3.75”
703 Trg Delay Timeout
Ext trigger delay has been
turned on, but the assigned
input did not go inactive
within the 30 seconds
allowed.
Check external timing.
Activate Ext Trg Delay.
706 Missing Part Abort
Checked during downstroke.
The missing part minimum
distance has not been
reached before trigger
occurred or the maximum
distance has been exceeded
before trigger occurred.
Insert a part into the
fixture. Use the horn
down feature to
determine the distance
to the part, and reset
the minimum and
maximum settings as
necessary through the
Alarm Information
screen or Setup menu.
708 Trig Before Pretrig
Trigger has occurred before
pre-trigger distance, upper
limit switch is inactive, or
pre-trigger time delay has
not timed out.
Check each condition
and correct where
necessary.
70C Abs Before Trg
The absolute distance has
been reached before trigger.
This alarm in other modes
means the absolute cutoff
distance has been reached
before trigger.
Reset your absolute
distance parameter
through the Alarm
Information screen or
the Setup menu.
70D
Amp Step Before
Trg
The amplitude step trigger
has been detected within 2
ms of start of weld time.
Reset your amplitude
step parameter through
the Alarm Information
screen or the Setup
menu.
70F Ground Detect
The ground detect input is
either improperly
configured, in the wrong
condition or failed.
Reconfigure properly,
change condition or
replace faulty input.
