6.9.18 Rapid Traverse
Allows a high horn travel speed for a portion of the stroke. Once the set distance is
reached, travel speed is reduced to the downspeed setting.
Figure 6.8 Rapid Traverse
6.9.19 Hold Pressure
Hold Pressure sets the actuator air pressure during the hold portion of a cycle. If set for
Default, the hold pressure will always equal the weld pressure. The hold pressure must
always be equal or greater than the weld pressure or a setup alarm will occur.
Figure 6.9 Hold Pressure
NOTICE
Distance should be set at least 1.0 inches above the actual distance
required to switch. Depending on your downspeed setting, the
distance may have to be adjusted to touch the part at the required
velocity.
