120 100-412-234 REV. 06
6.9.16 Weld Pressure
You can set the PSI pressure that will be delivered in any welding mode. The power
supply’s default is to use 50 PSI pressure. By changing the pressure to some lesser PSI, or
by setting the pressure to begin at one level and finish at another, you can “fine tune”
your overall welding procedure without making changes to your tooling (converter,
booster, horn, or fixture).
6.9.17 Downspeed
Sets the percent air flow from the actuator’s pneumatic cylinder for speed control. The
settings can be made between 1 and 100%, and the speed will depend on air pressure
and stroke length. The flow valve is motorized and does change instantaneous with
adjustments.
If the Downspeed Tuning function is on in the System Configuration screen, the flow valve
can be fine tuned to the actuator speed required.
NOTICE
You can select the amplitude to use only when Pressure is set to
Fixed. If pressure is Stepped, this parameter is inactive and the
display shows *** for Pressure.
NOTICE
Pressure B must be greater than or equal to Pressure A.
