6.19 Calibration
Use the Calibration Menu to calibrate the pressure sensor and force readout of the S-
Beam load cell. The actuator calibration may be required when changing the booster,
horn, or regulator pressure. You will be prompted to perform the actuator calibration the
first time you power up the system, or any time the controls sense a significant change in
the stack weight greater than five pounds. The sensor calibration is set at the factory and
should be good for the life of the system. But if you are operating under regulatory
requirements, calibrate the sensors according to their schedule and Branson standards.
For more detailed information on calibrating the sensors, you can contact Branson by
calling the Technical Support as indicated in 1.3 Warranty Statement, Disclaimer.
Figure 6.63 Calibration
DANGER
Before continuing, make sure all hands are away from the Horn and
base surface. The horn will accelerate rapidly to the base surface no
matter which screen you are in.
NOTICE
Velocity is not to be used for validation.
