Branson 2000Xc - Table D.3 Weld History Ids

290 100-412-234 REV. 06
D.4.2 Weld History IDs
Table D.3 Weld History IDs
ID Description ID Description
1 Cycle Count 20 Reserved
2 User ID 21 Reserved
3 Part-ID 22 Force B
4 Preset # 23 Force A
5 Preset Rev 24 Pressure
6 Preset Validated 25 Frequency Min
7 Actuator Assembly 26 Frequency Max
8 Power Supply Assembly 27 Frequency Start
9 Stack Assembly 28 Frequency End
10 Weld Time 29 Frequency Change
11 Peak Power 30 Cycle Time
12 Energy 31 Hold Force
13 Reserved 32 Trigger Force
14 Downspeed 33 Power Supply Serial #
15 Weld Absolute 34 Actuator Serial #
16 Total Absolute 35 Time
17 Weld Collapse 36 Date
18 Total Collapse 37 Preset Name
19 Amplitude Start 38* Alarm Info
NOTICE
*Alarm Info will only be populated with data in the return string if the
associated weld had an alarm. Otherwise this field will be empty.
