8.8.11 Line Fuses
To remove and replace the line fuses, take the following steps:
Reassemble the power supply by reversing the above procedure.
Table 8.14 Removing and Replacing the Line Fuses
Step Action
1 Turn off the power supply.
2 Unplug the main power.
3
Using a #2 Phillips screwdriver, remove 7 screws from the 2000Xc cover (3
on each side, 1 on the rear). Remove the cover.
4 Allow at least two minutes for capacitor discharge.
5
Rotate the DC power supply up to allow you access to the Line Board. See
8.8.6 DC Power Supply.
6 Remove and replace the line fuse(s) located on the Line Board.
