• Move the shipping container close to the intended installation location, leave it on the floor
• Open the top of the cardboard box, remove the insert from the top of the box and set it aside
• The toolkit, mounting bolts, and converter and/or booster are shipped with the actuator but in
separate shipping box(es). Unpack the converter, booster, toolkit and bolts from their packages
• Save the packing material
Figure 5.3 Ultrasonic Converter (J-Type for Stand-Alone Use) and Booster
NOTICE
The packaging may also include the converter and/or booster, if
ordered.
Booster
Converter
(J-type shown)
