100-412-234 REV. 06 109
6.4 Front Panel Controls
You use the color touchscreen on the front panel of the 2000Xc Power Supply to navigate
through all of the menus, set welding values, and view alarms about the most recently
completed weld.
You press the Reset Button when you encounter an alarm condition requiring that you
reset the power supply before performing another operation.
You press the Test Button to verify the integrity of the system setup. If the power supply
displays an alarm, find and address the alarm message definition in the Maintenance
section of Chapter 8: Maintenance of this manual.
6.4.1 Front Panel Color Touchscreen
You can perform the following navigational and operational functions on the power supply
front panel touchscreen:
• Touching the Weld Results Button will display the Weld Results from 7 weld cycles to be
monitored from the Weld Results screen
• Touching the Main Menu Button will display the Main Menu screen which access the Weld Setup,
Screen Setup, View Current Setup, Weld History, System Configuration, System Information,
Diagnostics, Save/Recall Presets, Sequencing Presets and USB options
• Touching the Weld Setup Button will display the Weld Setup screen which accesses the Weld
Mode, and all Weld Parameters
• Touching the Graphs Button will display the View Graphs, Auto Scale, X Scale and Auto Refresh
menu buttons
• Each of the preceding accessible buttons will provide the user with the appropriate navigation,
parameter and choice options to control the operation of the power supply
CAUTION
Do not use excessive force or a sharply pointed object to operate the
touchscreen.
