Branson 2000Xc - Table 8.4 2000 Xc Series System Cables (External); Table 8.5 Suggested Spares

100-412-234 REV. 06 201
8.4.2 System Cables
8.4.3 Suggested Spares
Table 8.4 2000Xc Series System Cables (External)
P/N Description Cable Model
101-241-202
Cable, Remote Interface 8' to remote
pneumatics package (ao actuator)
J924
101-241-203 Cable, Actuator Interface 8' J925S
101-241-204 Cable, Actuator Interface 15' J925S
101-241-205 Cable, Actuator Interface 25' J925S
101-241-207 Cable, User I/O 8' J957S
101-241-208 Cable, User I/O 15' J957S
101-241-209 Cable, User I/O 25' J957S
101-240-176 Cable, RF CR & CJ20 8' CE J931CS
101-240-177 Cable, RF CR & CJ20 15' CE J931CS
101-240-178 Cable, RF CR & CJ20 25' CE J931CS
100-246-630 Cable, Ground Detect -
NOTICE
Cables identified for ‘CJ-20 Converters’ are for those Converters
when they are installed in Branson 2000Xc Actuators. The cable
connects to the actuator.
Table 8.5 Suggested Spares
Description EDP #
1-4
Units
6-12
Units
14+
Units
Replacement 2000Xc Controller
Board
102-242-1025R 0 1 1
4 kw power supply module
(20 kHz)
159-244-075R 0 0 1
2.5 kw power supply module
(20 kHz)
100-244-103R 0 0 1
1.25 kw power supply module
(20 kHz)
100-244-102R 0 0 1
