100-412-234 REV. 06 175
6.20 USB
Use this menu to copy Weld History, Weld Setup, Event History, and User ID Table in PDF
format to the attached USB stick and to access the streaming data setup.
Figure 6.65 USB
6.20.1 Copy Now
Press the Weld History, Weld Setup, Event History, or User ID Table button to copy the
related data to the attached USB stick.
Figure 6.66 Copy Now
The PDF data will be saved in a folder named after the power supply serial number. The
date of the file is generated when the file is saved to the USB stick.
NOTICE
Welding will not be allowed during this operation.
