Branson 2000Xc - Table 5.3 Electrical Input Power Ratings

68 100-412-234 REV. 06
5.4.2 Electrical Input Power Ratings
Plug the power supply into a single-phase, grounded, 3-wire, 50 or 60 Hz power source.
Plug the power supply into a single-phase, grounded, 3-wire, 50 or 60 Hz power source.
Table 5.3 lists the current and fuse ratings for the various models.
The ground screw on the rear of the actuator must be connected to earth ground with #8
gauge wire.
Input Power Requirements
Table 5.3 Electrical Input Power Ratings
Model Power Current Rating
20 kHz
1250 W 200V - 240V 7 Amp Max. @ 200V / 20 Amp fuse
NEMA L6-20P
Plug
2500 W 200V - 240V
14 Amp Max. @ 200V / 20 Amp
fuse
NEMA L6-20P
Plug
4000 W 220V - 240V
25 Amp Max. @ 220V / 25 Amp
fuse
NEMA L6-20P
Plug
30 kHz
750 W 220V - 240V 5 Amp Max. @ 200V / 20 Amp fuse
NEMA L6-20P
Plug
1500 W 200V - 240V
10 Amp Max. @ 200V / 20 Amp
fuse
NEMA L6-20P
Plug
40 kHz
400 W 200V - 240V 3 Amp Max. @ 200V / 20 Amp fuse
NEMA L6-20P
Plug
800 W 200V - 240V 5 Amp Max. @ 200V / 20 Amp fuse
NEMA L6-20P
Plug
