5.8 Assemble the Acoustic Stack
CAUTION
The following procedure must be performed by a setup person. If
necessary, secure the largest portion of a square or rectangular horn
in a soft jawed (brass or aluminum) vise. NEVER attempt to assemble
or remove a horn by holding the converter housing or the booster
clamp ring in a vise.
CAUTION
Do not use silicone grease with Mylar washers. Use only 1 (one)
Mylar washer of the correct inside and outside diameters at each
interface.
CAUTION
No Mylar washers for 40 kHz. Use silicone grease for 40 kHz.
Table 5.9 Tools, Grease and Mylar Washers
Tool EDP Number
20, and 30 kHz Torque Wrench Kit 101-063-787
40 kHz Torque Wrench 101-063-618
20 kHz Spanner Wrench 101-118-039
30 kHz Spanner Wrench 201-118-033
40 kHz Spanner Wrench 201-118-024
Silicone Grease 101-053-002
Kit 20 kHz, 10 each (1/2 in. and 3/8 in) 100-063-357
Kit 20 kHz, 150 each (1/2 in.) 100-063-471
Kit 20 kHz, 150 each (3/8 in.) 100-063-472
Kit 30 kHz, 10 each (3/8 in., 30 kHz) 100-063-632
