100-412-234 REV. 06 85
3
Noting that one side of each bracket is countersunk to accept the provided
flathead screws, assemble the Rack Mount Handles as shown in Figure 5.14.
(This shows only the Right bracket and handle; the left side is a mirror-
image.) Tighten the screws securely and so they are flush.
4
Re-using the screws you removed in Step 2, install the assembled Handle in
place of the Front Corner pieces.
5 Save the removed hardware corner pieces.
6
When you are ready to install the unit, use the hardware from your Rack
Mounting system to locate the power supply.
Table 5.8 Rack Mount Installation
Step Procedure
