3.3 Unpacking
3.3.1 Actuator Assemblies
Actuator assemblies are heavy and packed in a protective shipping container. The booster,
converter, and actuator toolkit are often packed inside the shipping container.
Each actuator is shipped as one of the two assemblies described below, with its own
corresponding unpacking procedure. These assemblies vary in both the materials used for
shipping and the actual components that you will receive when the actuator is shipped.
For complete actuator unpacking and installation procedures, refer to Chapter 5:
Installation and Setup
• Stand (Actuator on Base): A stand consisting of an actuator on a base is shipped on a wooden
pallet with a cardboard box cover. (The packaging for this assembly is similar to that of an
actuator on hub-mounted column)
• Actuator (Alone): An actuator that does not use either type of stand is shipped in a rigid
cardboard box using protective foam shells for support
3.3.2 Power Supply
The power supply is fully assembled. It is shipped in a sturdy cardboard box. Some
additional items are shipped in the box with the power supply.
When unpacking the power supply, take the following steps:
Table 3.3 Unpacking Procedure
Step Action
1
Unpack the power supply as soon as it arrives. Save the packing
material.
2 Inspect the controls, indicators, and surface for signs of damage.
3
Remove the cover of the power supply (8.8 Parts Replacement) to check
if any components became loose during shipping.
NOTICE
If damage has occurred, notify the shipping company immediately.
Retain packing materials for inspection.
