Branson 2000Xc - Table 6.22 Weld History

100-412-234 REV. 06 145
6.10.24 Weld History Setup
Select which parameters will be shown in Weld History. Available parameters are:
Table 6.22 Weld History
Name Description
Weld Time Ultrasonic weld time during cycle.
Peak Pwr Peak Power. Peak power achieved during ultrasonic cycle.
Energy Ultrasonic Energy applied during the weld.
Velocity Velocity of actuator 1/4 inches before part contact.
Weld Abs
Weld Absolute. Distance the actuator traveled from home position to
end of ultrasonic weld.
Total Abs
Total Absolute. Distance the actuator traveled from home position to
end of hold time.
Weld Col
Weld Collapse. Distance the actuator traveled from part contact to end
of ultrasonic weld.
Total Col
Total Collapse. Distance the actuator traveled from part contact to end
of hold time.
Set Amp A
Set Amplitude A. Amplitude percentage of ultrasonics for fixed
amplitude and first part of amplitude step.
Set Amp B
Set Amplitude B. Amplitude percentage of ultrasonics for second part
of amplitude step.
Weld Force Actuator force at end of weld.
Act Pressure Actuator Pressure. Pressure during weld.
Freq Min
Frequency Minimum. Minimum ultrasonic frequency measured during
the weld cycle.
Freq Max
Frequency Maximum. Maximum ultrasonic frequency measured during
the weld cycle.
Freq Start
Frequency Start. Starting ultrasonic frequency of the horn during the
weld cycle.
Freq End
Frequency End. Ending ultrasonic frequency of the horn during the
weld cycle.
Freq Change Frequency Change. Frequency Max minus Frequency Min.
Cycle Time
Total cycle time from the actuator leaving the home position to
returning to the home position.
Hold Force Actuator force at end of hold.
