Branson 2000Xc - Table B.4 Suspect;Reject Alarms and Messages, with Probable Cause and Corrective Action

236 100-412-234 REV. 06
B.1.5 Suspect or Reject Alarms
Table B.4 Suspect/Reject Alarms and Messages, with Probable Cause and Corrective Action
Alarm
ID
Display Message
Alarm Condition/
Cause
Corrective Action
500 - R Trg Dist Limit
The actual trigger
distance value did not
reach the minus reject
trigger distance limit.
Adjust - reject trigger
distance limit through the
Alarm Information screen
or Setup menu. Discard
the part if you encounter
numerous or successive
alarms.
503 +R Pk Power Limit
The actual peak power
value exceeded the plus
reject peak power limit.
Discard the part if you
encounter numerous or
successive alarms with
good parts. Consider
changing your Peak Power
settings.
504 - R Pk Power Limit
The peak power used in
the most recent weld was
less than the lower reject
limit you set.
Discard the part. If you
encounter numerous or
successive alarms with
good parts, you might
change your reject peak
power limits.
505 - R Time Limit
The actual time value did
not reach the minus
reject time limit.
Discard the part if you
encounter numerous or
successive alarms with
good parts. Consider
changing your Time
settings.
506 +R Time Limit
The actual time value
exceeded the plus reject
time limit.
Discard the part if you
encounter numerous or
successive alarms with
good parts. Consider
changing your Time
settings or your reject
time limits.
507 - R Energy Limit
The energy used in the
most recent weld was
less than the lower reject
limit you set.
Discard the part. If you
encounter numerous or
successive alarms with
good parts, you might
change your reject energy
limits.
508 +R Energy Limit
The energy used in the
most recent weld was
greater than the upper
reject limit you set.
Discard the part. If you
encounter numerous or
successive alarms with
good parts, you might
change your reject energy
limits.
