Branson 2000Xc - Figure 6.38 Actuator Settings; Table 6.21 Actuator Settings

144 100-412-234 REV. 06
6.10.23 Act Settings
Change actuator settings.
Figure 6.38 Actuator Settings
Table 6.21 Actuator Settings
Name Description
Cyl Dia Set the cylinder diameters.
Cyl Stroke Set the cylinder stroke.
Custom Set the upper limit switch and ground detect to 0 V or 24 V.
Part Contact Set the velocity and force.
Min Trigger Set the minimum trigger in lb.
Metric decimals Set the number of metric decimals.
