6.9 Weld Setup
The Weld Setup Menu allows you to select and set all the parameters necessary to
successfully operate in any available mode. The following parameters are available in Weld
Setup.
Table 6.7 Weld Setup, Page 1
Weld Setup
Weld Modes Trigger
Trigger Force
Trigger Distance
Weld Time, Weld Energy, Peak Power,
Collapse, Absolute, Scrub Time
Amplitude Step
Scrub Amplitude
Hold Time
Amplitude Step Pressure
Table 6.8 Weld Setup, Page 2
Weld Setup
Weld Pressure Downspeed
Rapid Traverse Hold Pressure
Pretrigger Save/Recall Presets
Write In Field Batch Setup
Table 6.9 Weld Setup, Page 3
Weld Setup
Afterburst Control Limits
Act Clr Output Cycle Aborts
Pressure Limit Power Match Curve
Ext U/S Delay Digital UPS
Table 6.10 Weld Setup, Page 4
Weld Setup
Post Weld Seek Reject Limits
Energy Brake Suspect Limits
Frequency Offset
Timeout
Downspeed Tuning
Setup Limits
