4.1.4 Actuator Performance Specifications
The following tables detail some of the performance specifications associated with the
2000Xc Actuator.
Minimum Stroke:1/8” / 3.2 mm
Maximum Stroke: 3-3/4” / 95.2 mm (for a 4" cylinder)
Table 4.4 Maximum Welding Force (at 100 psig and 4.0” stroke)
1.5" cylinder 135 lb. / 61.4 k
2.0” cylinder 269 lb. / 122.3 k.
2.5" cylinder 441 lb / 200.5 k.
3.0” cylinder 651 lb. / 295.9 k.
3.25" cylinder 772 lb. / 350.9 k.
Table 4.5 Dynamic Trigger Force
1.5" and 2.0" cylinder 5 lb. / 2.25 k to max force
2.5", 3.0", and 3.25" cylinder 10 lb./ 4.5 k. to max force
Table 4.6 Dynamic Follow-Through
1.5", 2.0" 15 lb. / 6.8 k. to max force
2.5", 3.0", 3.25" 15 - 400 lb. / 6.8 - 181.8 k.
Table 4.7 Maximum Traverse Speed (Application dependant)
Down and Return
Speed
Up to 7 inch/ 177.8 mm per sec. max at 3.5-inch / 88.9 mm
stroke, 90 psi (all cylinder sizes)
