4.1 Technical Specifications
4.1.1 Environmental Requirements
4.1.2 Electrical Requirements
The following tables list input voltage and current requirements for the 2000Xc Power
Supply, and includes power required when it is used with Branson 2000Xc-series
Actuators.
*This unit is rated at a 25% duty cycle with 5 second On time, 2000W continuous. Rated power is 4000W at
40°C.
Table 4.1 Environmental Specifications
Environmental Concern Acceptable Range
Ambient Operating Temperature +41°F to +104°F (+5°C to +40°C)
Storage/Shipping Temperature -13°F to +131°F (-25°C to +55°C)
Shock/Vibration (transit)
18" & 36" height shock and 1-200 Hz vibration per
ISTA 3A
Operating Altitude Up to 6560 ft (2000 m)
Humidity Maximum 95%, non-condensing
IP Rating 2X
Table 4.2 Electrical Input Operating Voltages
Power Supply Rating Nominal Input Operating Voltage, +/-10%
40 kHz / 400 W 200- 240 V, 50/60 Hz, Single Phase
40 kHz / 800 W 200- 240 V, 50/60 Hz, Single Phase
30 kHz / 1500 W 200- 240 V, 50/60 Hz, Single Phase
20 kHz / 1250 W 200- 240 V, 50/60 Hz, Single Phase
20 kHz / 2500 W 200- 240 V, 50/60 Hz, Single Phase
20 kHz / 4000 W* 220- 253 V, 50/60 Hz, Single Phase
Table 4.3 Input Current and Fuse Requirements
Model Power Current Rating
20 kHz
1250 W 200V - 240V 7 Amp Max. @ 200V / 20 Amp fuse
2500 W 200V - 240V 14 Amp Max. @ 200V / 20 Amp fuse
4000 W* 220V - 253V 25 Amp Max. @ 220V / 25 Amp fuse
30 kHz
750 W 200V - 240V 5 Amp Max. @ 200V / 20 Amp fuse
1500 W 200V - 240V 10 Amp Max. @ 200V / 20 Amp fuse
