150 100-412-234 REV. 06
6.10.35.1 Data String Sample Output
The following examples illustrate the data string that is sent out through the serial port
after each weld. The table following these data strings shows the relationship between
control levels. IDID can be any number from 1 to 9999. Table headings 1 through 4
respectively reference data string examples 1 through 4.
Table 6.23 Sample Output for Control Level t with an ae actuator
Output Units
DID@cccccccc@hh:mm:ss@MM/DD/YY@Mode@tt.ttt@sfff@aaaCRLF
USCS
IDID@cccccccc@hh:mm:ss@DD/MM/YY@Mode@tt.ttt@sfff@aaaCRLF
Metric
Table 6.24 Sample output for Control Level ea, d, or f with an ae actuator
Output Units
IDID@cccccccc@hh:mm:ss@MM/DD/YY@Mode@tt.ttt@ppp.p@eeeee@sfff@aaa@bbbCRLF
USCS
IDID@cccccccc@hh:mm:ss@DD/MM/YY@Mode@tt.ttt@ppp.p@eeeee@sfff@aaa@bbbCRLF
Metric
Table 6.25 Sample Output for Control Level d or f with an aed actuator
Output Units
IDID@cccccccc@hh:mm:ss@MM/DD/
YY@Mode@tt.ttt@ppp.p@eeeee@w.wwww@z.zzzz@x.xxxx@FFF@hhh@sfff@aaa@bbb@vv.vCR
LF
USCS
IDID@cccccccc@hh:mm:ss@DD/MM/
YY@Mode@tt.ttt@ppp.p@eeeee@ww.www@zz.zzz@xx.xxx@FFF@hhh@sfff@aaa@bbb@vv.vCR
LF
Metric
Table 6.26 Sample Output for Control Level f with an aef actuator
Output Units
IDID@cccccccc@hh:mm:ss@MM/DD/
YY@Mode@tt.ttt@ppp.p@eeeee@w.wwww@z.zzzz@x.xxxx@FFF@AAA@BBB@hhh@sfff@aaa@
bbb@vv.vCRLF
USCS
IDID@cccccccc@hh:mm:ss@DD/MM/
YY@Mode@tt.ttt@ppp.p@eeeee@ww.www@zz.zzz@xx.xxx@FFF@AAA@BBB@hhh@sfff@aaa@
bbb@vv.vCRLF
Metric
