B.1.8 Note Alarms
In addition to the previously described alarms there are several Note alarms that the
Controls can issue to alert you that an alarm is imminent, or that the cycle ran with
authorized modifications.
The following table details the Note alarms you can encounter on the 2000Xc Power
Supply. The message on the display panel of the power supply is shown in the first
column; the detailed message is in the second column. The third and fourth columns
indicate the condition that led to the alarm and the corrective action you should take.
Table B.7 Note Alarms and Messages, with Probable Cause and Corrective Action
Alarm
ID
Display Message Alarm Condition/Cause Corrective Action
416 Absolute Cutoff
The absolute cutoff
distance that you
requested has been
reached.
Manually inspect the part.
If, with acceptable parts,
you repeatedly get this
alarm, reset your Absolute
cutoff.
417
Act Clr Not
Reached
The actual absolute
distance reached during
the weld cycle did not
reach the actuator clear
distance that you set.
Using Horn Down to
obtain size and distance
readings, reset your
Actuator Clear Distance to
an obtainable value.
418
Max Energy
Reached
The maximum energy
compensation value has
been reached.
None. This is only a notice
that an adaptive control
feature that you
programmed is in use.
421 Sonics Disabled
A complete weld cycle has
been run but the
ultrasonics were disabled
by a user defined input.
Remove 24V from Sonics
Disable input; undefined
Sonics Disable input pin.
422
USB Memory
Nearly Full
The USB memory stick is
over 98% full. At the
current rate of storing,
this is enough room for
less than 100 welds.
When full the welder will
stop cycling.
Replace USB memory
stick.
41D Time Extended
Weld time has been ex-
ended up to 50% for
energy compensation.
This alarm occurs in Time
Mode only.
None. This is only a notice
that an adaptive control
feature that you
programmed is in use.
41E
Act Recal
Suggested
A preset has been loaded
and calibration should be
run
Calibrate actuator through
Note menu, or calibrate
from the Main Menu.
