Branson 2000Xc - Ids; Table D.2 Parameter Ids

282 100-412-234 REV. 06
D.4 IDs
D.4.1 Parameter IDs
Table D.2 Parameter IDs
ID JSON Description Description Unit Min Value Max Value
Weld Setup
15 Amplitude1 Amplitude % 10 100
249 AMP_1 Amplitude % 10 100
35 Downspeed Downspeed % 1 100
87 Hold_Time Hold Time s 0.010 30.000
248 PRESSURE1 Weld Pressure PSI 10 100
248 PRESSURE1 Weld Pressure kPa 69 689
127 Trigger_Type Trigger N/A 0 1
128 Trigger_Distance Trigger Distance in 0.1250 4.0000
128 Trigger_Distance Trigger Distance mm 3.18 101.60
129 Trigger_Force Trigger Force lb 5 159
129 Trigger_Force Trigger Force N 22 707
Save/Recall Presets
137 Validate_Preset Validate N/A - -
138 Lock_Preset Lock N/A - -
Current Setup
117 Test_Amplitude Test Amplitude % 10 100
Amplitude Step
206 Amplitude_Step_Enable Amplitude Fixed/Step N/A 0 1
15 Amplitude1 Amplitude A % 10 100
23 Amplitude2 Amplitude B % 10 100
17 Amp_Step_Col_Val Step @ Col in 0.0004 1.0000
17 Amp_Step_Col_Val Step @ Col mm 0.01 25.40
18 Amp_Step_Ext_Enable Step @ Ext Sig N/A 1 1
19 Amp_Step_Time_Val Step @ T s 0.010 30.000
20 Amp_Step_E_Val Step @ E J 1 45000
21 Amp_Step_Power_Val Step @ Pwr % 1.0 100.0
Pressure Step
246 PRESSURE2_FLAG Pressure Step/Fixed N/A 0 1
248 PRESSURE_1 Pressure A PSI 10 100
248 PRESSURE_1 Pressure A kPa 69 689
247 PRESSURE_2 Pressure B PSI 10 100
