Table 5.5 User I/O Cable Pin Assignments
Pin Signal Name Signal Type Directio Colors
1 J3_1_INPUT 24 V Logic 1 True Input White/Black
2 CYCLE_ABORT 24 V Logic 1 True Input Red/Black
3 EXT_RESET 24 V Logic 1 True Input Green/Black
4 SOL_VALVE_SRC +24 V Output Orange/Black
5 REJECT 24 V Logic 0 True Output Blue/Black
6 G_ALARM 24 V Logic 0 True Output Black/White
7 ACT_CLEAR 24 V Logic 0 True Output Red/White
8 J3_8_OUTPUT 24 V Logic 0 True Output Green/White
9 MEMORY Analog Output Blue/White
10 USER_AMP_IN Analog Input Black/Red
11 MEM_CLEAR 24 V Logic 0 True Output White/Red
12 GND Orange/Red
13 +24V Blue/Red
14 G_ALARM_RELAY_1 Relay Contact Output Red/Green
15 READY_RELAY_2 Relay Contact Output Orange//Green
16 SV1RTN +24 V return Input Black/White/Red
17 J3_17_INPUT 24 V Logic 1 True Input White/Black/Red
18 USER_EXT_SEEK+ 24 V Logic 1 True Input Red/Black/Green
19 J3_19_INPUT 24 V Logic 1 True Input Green/Black/White
20 SUSPECT 24 V Logic 0 True Output Orange/Black/White
21 READY 24 V Logic 0 True Output Blue/Black/White
22 J3_22_OUTPUT 24 V Logic 0 True Output Black/Red/Green
23 10V_REF Analog Output White/Red/Green
24 AMPLITUDE_OUT Analog Output Red/Black/Green
25 USER_FREQ_OFFSET Analog Input Green/Black/Orange
26 RUN 24 V Logic 0 True Output Orange/Black/Green
27 GND Blue/White/Orange
28 +24V Black/White/Orange
29 G_ALARM_RELAY_2 Relay Contact Output White/Red/Orange
30 WELD_ON_RELAY_1 Relay Contact Output Orange/White/Blue
31 J3_31_INPUT 24 V Logic 1 True Input White/Red/Blue
32 J3_32_INPUT 24 V Logic 1 True Input Black/White/Green
33 J3_33_INPUT 24 V Logic 1 True Input White/Black/Green
34 PB_RELEASE 24 V Logic 0 True Output Red/White/Green
35 WELD_ON 24 V Logic 0 True Output Green/White/Blue
36 J3_36_OUTPUT 24 V Logic 0 True Output Orange/Red/Green
37 PWR Analog Output Blue/Red/Green
38 FREQ_OUT Analog Output Black/White/Blue
39 SEEK 24 V Logic 0 True Output White/Black/Blue
