64 100-412-234 REV. 06
5.4 Installation Requirements
This section covers the location options, dimensions of the major assemblies,
environmental requirements, electrical requirements and factory air requirements, to help
you plan and execute your installation successfully.
5.4.1 Location
The actuator or stand may be installed in a variety of positions. The stand (on a base) is
often manually operated, using its base-mounted start switches, and so is installed at a
safe and comfortable workbench height (approximately 30-36 inches) with the operator
sitting or standing in front of the system. Actuators alone can be mounted in any
orientation, Contact Branson if mounting upside down.
The stand may tip over if moved around the axis of its column, if not properly secured.
The work surface on which a stand is installed must be sturdy enough to support it, and
secure enough to not tip over when the stand is adjusted during installation or setup.
The 2000Xc Power Supply must not be positioned so that is difficult to plug in or unplug
the main power plug.
The power supply may be located up to 50 feet away for 20kHz (20' for 30kHz, and 15' for
40kHz models) from the actuator. The power supply must be accessible for user
parameter changes and settings, and must be placed in a horizontal orientation. The
power supply should be positioned so it does not draw in dust, dirt or material via its rear
fans. Refer to the illustrations on the pages that follow for a dimensional drawing of each
component. All dimensions are approximate and may vary between models:
Figure 5.4 Power Supply Dimensional Drawing
Figure 5.5 2000Xc Actuator Dimensional Drawing
