Branson 2000Xc - Figure 6.64 Cal Actuator

To Next Page

To Previous Page

174 100-412-234 REV. 06

6.19.1 Cal Actuator

Press the W/Start Switches button to perform the calibration using the start switches.

Press the W/Manual Override button to perform the calibration using the manual override

on valve.

Figure 6.64 Cal Actuator

6.19.2 Call Full System

NOTICE

Cal Full System requires critical test instruments. This should only be

performed by qualified personnel. Contact your Branson

representative for specific information regarding this calibration.
